The General Features of Our I.V. Cannula are





•  Catheter is made from Medical Grade Virgin PTFE (Teflon) is of Internationally accepted high quality
•  PTFE Tubing-The Most Bio- Compatible Material, with longer indwelling time.
•  PTFE has lowest co-efficient of friction, thereby smoothening the insertion.
•  Port / Injection Valve with Non-return silicon valve for intermittent medication.
•  Colour coded cap for easy gauge identification.
•  Sharp 3 facet bevel with back cut Imported needle to reduce the penetration force for the ease of cannulation.
•  Types of IV Cannula - IV Cannula Sizes Flow Rates and Color Codes, Complications, IV Cannula Sizes, IV Cannula Insertion



Iv Cannula Insertion

Fine Polished Triple Bevelled Tip and US made Catheter tipping fixtures facilitate smoother IV Cannula Insertion

Gauge Specifications

COLOR CODE		GAUGE	OD m.m.	LENGTH	FLOW RATE ml/min.
	Orange	14G	2.10	45	290
	Medium Grey	16G	1.70	45	176
	White	17G	1.50	45	130
	Deep Green	18G	1.30	45	76
	Pink	20G	1.00	33	54
	Deep Blue	22G	0.85	25	31
	Yellow	24G	0.70	19	14
	Violet	26G	0.60	19	13
